FLEXCEL NXC Plates

FLEXCEL NXC Plates Bringing modern flexo to corrugated board

FLEXCEL NXC Plates deliver consistent color and production efficiencies to corrugated board.

FLEXCEL NXC Features

Designed for direct print applications on boards with a variety of liner and flute types, and with water-based inks, FLEXCEL NXC Plates can take on a diverse array of graphic challenges from simple line and tone designs through to complex process colour artwork.

Maximum versatility, enhanced productivity

FLEXCEL NXC Plates are designed to print with water-based inks on post-print board with a wide variety of liner and flute types. They are suitable for a broad range of graphic reproduction requirements from simple line and tone work, to complex full process color content.

1:1 dot replication for exceptional print performanceermal Imaging Layer

For post-print corrugated applications we offer FLEXCEL NXC Plate Kits in a wide variety of sizes. Plate kits provide the two key materials required to create a finished FLEXCEL NXC Plate. The FLEXCEL NX Thermal Imaging Layer-R is designed to provide rapid, high-resolution imaging on the FLEXCEL NX System, and delivers a stable and predictable imaged mask for plate exposure. Lamination ensures intimate optical contact between the imaged layer and the FLEXCEL NXC Plate, allowing 1:1 dot reproduction onto the plate, and support for advanced plate surface patterning.

Packaged for efficiency, supported by Miraclon

FLEXCEL NXC Plates are high-quality, lower durometer flexographic plates that provide full tonal reproduction, low dot gain, and robust on-press performance. Higher line screens are possible with existing press equipment, and excellent ink transfer and coverage minimizes fluting and increases visual impact, even on lower quality liner materials.

How It Works?

FLEXCEL NXC Plates deliver reliable, consistent results across all packaging materials while achieving high productivity and efficient workflow with resilience for high press speeds and durability for repeat print runs.

Thermal Imaging with Precision

FLEXCEL NXC Plate Kits include the NX Thermal Imaging Layer-R, which is rapidly imaged using the FLEXCEL NX System to create a stable and predictable mask for plate exposure.

1:1 Dot Reproduction through Lamination

The imaged layer is laminated to the plate to ensure precise 1:1 dot transfer, which allows for highly accurate graphic reproduction and supports advanced surface patterning.

highly accurate graphic reproduction and supports advanced surface patterning. Optimized for Post-Print Corrugated

Specifically developed for post-print corrugated packaging, the system delivers excellent quality on various board types using water-based inks—ensuring flexibility and reliability across materials.

Know More About NXC PLATE

FLEXCEL SR Plates combine outstanding performance with DITR Film technology, delivering dependable solutions for package printing operations with wide tonal range, excellent productivity and print stability.

Exceptional Print Quality

Produces full tonal range, low dot gain, and high line screens with superb ink transfer and coverage, minimizing fluting and enhancing image sharpness even on low-quality liners.

Maximum Versatility

Suitable for a wide range of graphics—from simple line work to complex process color—across different flute and liner types using water-based inks.

Efficient Workflow

Offers wide exposure latitude and fast drying times, helping meet tight production deadlines without compromising on print quality.

High Durability

Designed to resist ozone, wear, and abrasion, these plates are built for longevity and repeat use, maintaining consistency over multiple runs.

Easy Handling & Mounting

FLEXCEL NXC Plates are easy to mount and handle, reducing setup time and ensuring smoother press operations.

Integrated System from a Trusted Partner

Miraclon’s end-to-end technology and industry partnerships ensure you’re working with a world-class solution tailored for efficiency and quality in packaging production.

Technical Specifications

FLEXCEL NXC PLATE KITS
A wide range of finished plate size options are available. Contact your sales representative for more details.
Nominal plate size	33.46 x 70.86 inch	42.0 x 60.0 inch	42.0 x 80.0 inch	50.0 x 65.0 inch	50.0 x 80.0 inch
	850 x 1800 mm	1067 x 1524 mm	1067 x 2032 mm	1270 x 1651 mm	1270 x 2032 mm
Thermal Imaging Layer (TIL-R)	6.5 mil (0.0065 inch)	•	•	•	•
Safelight recommendations	Prolonged exposure should be under process yellow or UV-modified fluorescent light
Storage	Store flat and use in a controlled environment of 17 - 30°C (63 - 86°F) and at 40 - 60% RH
Handling	Handle the film by the corners. Avoid scratching and kinking. Handle the plates carefully.
